Forklift Starters

Forklift Starters - The starter motor nowadays is typically either a series-parallel wound direct current electric motor which consists of a starter solenoid, that is similar to a relay mounted on it, or it could be a permanent-magnet composition. Once current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion that is located on the driveshaft and meshes the pinion utilizing the starter ring gear which is seen on the engine flywheel.

As soon as the starter motor begins to turn, the solenoid closes the high-current contacts. Once the engine has started, the solenoid consists of a key operated switch that opens the spring assembly in order to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This permits the pinion to transmit drive in only a single direction. Drive is transmitted in this particular manner via the pinion to the flywheel ring gear. The pinion remains engaged, for example for the reason that the driver fails to release the key as soon as the engine starts or if there is a short and the solenoid remains engaged. This actually causes the pinion to spin independently of its driveshaft.

This aforementioned action stops the engine from driving the starter. This is an essential step since this particular kind of back drive will enable the starter to spin very fast that it would fly apart. Unless modifications were done, the sprag clutch arrangement would prevent using the starter as a generator if it was used in the hybrid scheme discussed earlier. Normally a regular starter motor is intended for intermittent utilization that will prevent it being used as a generator.

Therefore, the electrical components are intended to be able to operate for roughly under 30 seconds to avoid overheating. The overheating results from very slow dissipation of heat due to ohmic losses. The electrical components are designed to save cost and weight. This is really the reason the majority of owner's handbooks meant for automobiles recommend the driver to stop for at least ten seconds right after each and every ten or fifteen seconds of cranking the engine, if trying to start an engine that does not turn over instantly.

During the early 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Previous to that time, a Bendix drive was used. The Bendix system operates by placing the starter drive pinion on a helically cut driveshaft. As soon as the starter motor begins spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, thus engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear allows the pinion to surpass the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.

The development of Bendix drive was developed during the 1930's with the overrunning-clutch design called the Bendix Folo-Thru drive, made and introduced in the 1960s. The Folo-Thru drive has a latching mechanism along with a set of flyweights in the body of the drive unit. This was better because the typical Bendix drive used in order to disengage from the ring once the engine fired, though it did not stay running.

The drive unit if force forward by inertia on the helical shaft when the starter motor is engaged and begins turning. Then the starter motor becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, like for example it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and enables the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement can be avoided prior to a successful engine start.
